Fiberglass Unidirectional Fabric 0°
share
Multiaxial Fabrics—Warp UD cloth is weaved with direct roving along the warp (0°) direction, also can select to add chopping layer (300-600 g/m²), using the polyester stitching yarn to stitch together.
The area weight can be 300g/ m² ~1800g/ m², and the width can be 100-2540mm. Properties:
1)Fiber straight arranged
2)High strength along the roving
3)Binder free
It's mainly applied to wind blade, FRP pipe, pultruded parts, sports equipment, etc.
The area weight can be 300g/ m² ~1800g/ m², and the width can be 100-2540mm. Properties:
1)Fiber straight arranged
2)High strength along the roving
3)Binder free
It's mainly applied to wind blade, FRP pipe, pultruded parts, sports equipment, etc.
Detail
| Product Code | Gram(g/m²) | 0° gram(g/m²) | 90° gram(g/m²) | Chopping layer gram(g/m²) |
| UD300 | 338 | 282 | 45 | |
| UD600 | 640 | 550 | 45 | |
| UD900 | 920 | 850 | 60 | |
| UD1200 | 1200 | 1131 | 60 | |
| UDM1250 | 1250 | 1131 | 60 | 50 |
